Description
Technical Specifications
| Frequency Ranges: | 150-470 and 830---960 MHz in 20MHz sub-bands |
| Modulation: | FM Class F3 or lower deviation upon request |
| Output Impedace & Connector: | 50 ohm type 'N' female |
| RF Output power: | 10W or 20W |
| RF output power adjusting | 100% or 20% in front panel selectable |
| Harmoniic level (ref.to carrier): | < -75 dB |
| Spurious level (ref.to carrier: | < -80 dB |
| Frequency stability: | 2,5 ppm |
| Imput impedance: | 600 ohms or greater |
| Input Level: | - 6.dBm to +10 dBm nominal for nominal deviation adj. |
| Mono Input (with pre-emphasis): | Pre-emphasis 50/75 s selectable |
| Audio Bandwithh: | Standard 7,5 KHz ethers upon request |
| Distortion (THD) in compression: | < 2% |
| S:N Ratio (ref. to 25 KHz 1000 Hz): | >50 dB |
| Power requirements: | Operating voltage 100 to 240 ± 20% Vac 50/60Hz External DC 13.5V 3- 5 A (2,7A with 15Wout) |
| Power consumption: | 50/70 VA |
| Battery belt-pack (optional): | 13.5 Vdc 9.0 A |
| Operating temperature | 0 to +50°C |
| Relative humidity | 95% max non condensing |
| Dimensions: | Width 20cm Height 9cm Depht 27cm |
| Weight: | 4,5 kg |
